Parkade Waterproofing in Vancouver
Allweathercoating applies heavy-duty vehicular traffic deck coatings and waterproofing membranes to protect parkade concrete structures from water ingress and salt corrosion.
Common Problems Solved
- Rainwater dripped from cars carrying road salt, which eats away at concrete reinforcement.
- Cracked concrete slabs allowing water to leak onto cars below, causing paint damage.
- Moisture penetrating parkade walls, leading to mold and dark, damp environments.
- Loud tire squealing and poor reflectivity in dark, unpainted parkades.
Benefits for Property Managers
- Protects structural steel rebar from road salt corrosion.
- Eliminates chemical drippings and calcite stains on tenant vehicles.
- Reflective coatings brighten parkades, improving resident safety.
- Textured surfaces reduce tire squealing and hydroplaning.
Our Execution Process
Preparation
Shot-blast or diamond-grind the concrete slab to open pores.
Crack Injection
Inject polyurethane or epoxy resins into cracks to seal them structurally.
Primer Seal
Apply a high-penetration concrete primer.
Base Coating
Install elastomeric polyurethane waterproofing membrane.
Wear Course
Apply a heavy-duty aggregate layer in drive lanes to withstand tire wear.
Stripe Line
Re-paint parking stalls, directional arrows, and safety indicators.
Parkade Deck Waterproofing & Traffic Coating Specifications
Underground parkades are massive concrete structures that support the weight of vehicles while acting as foundations for the buildings above. Parkade decks face harsh conditions: vehicle wheel wear, oil/grease leaks, and water brought in by cars. In winter, this water is filled with road salts and de-icing chemicals. If the concrete is not protected, salt-laden water seeps into concrete slabs, corroding reinforcement rebar and causing concrete deterioration. Allweathercoating installs traffic-grade elastomeric waterproofing membranes that seal parkade concrete, protecting the building structure.
Traffic Coating System Architecture
Vehicular traffic membranes are multi-layered polyurethane systems designed to handle structural movement and vehicle weight:
- Primer Coat: A high-penetration epoxy primer that seals the concrete pores and creates a strong bond.
- Base Membrane: A flexible, elastomeric polyurethane layer that bridges concrete hairline cracks and provides the primary waterproof barrier.
- Wear Course: A tough polyurethane layer embedded with silica sand or bauxite aggregate to provide traction and resist tire wear.
- UV Topcoat: A chemical-resistant top layer that shields the system from oil leaks, road salt, and UV exposure.
Substrate Preparation: Shot-Blasting & Concrete Repair
Because vehicles generate high shear forces, parkade coatings require maximum adhesion. We prepare concrete using shot-blasting or diamond grinding to achieve an ICRI concrete surface profile (CSP) of 3 to 5. We repair concrete cracks using polyurethane injection resins or structural mortars, and we seal expansion joints with heavy-duty T-joint sealants before applying coatings.
Concrete Carbonation & Structural Corrosion Mitigation
In addition to surface wear, underground parkades are susceptible to concrete carbonation. When carbon dioxide from vehicle exhaust reacts with calcium hydroxide in the cement paste, it lowers the natural alkalinity of the concrete (dropping the pH from 12-13 down to 9). This neutral pH destroys the passive protection layer around the structural steel rebar, allowing moisture and oxygen to rust the iron. Rusting rebar expands up to 600% in volume, generating high tensile stress that fractures and delaminates the concrete. By sealing the concrete deck with our low-permeability elastomeric traffic coatings, we block the path of carbon dioxide, water, and road salts, arresting carbonation and preventing structural spalling.
Safety & Visibility Enhancements
Parkades are dark, high-risk environments. Applying traffic coatings brightens parkades, reflecting overhead light and improving driver and pedestrian safety. After applying the coating, we repaint parking stalls, directional arrows, and safety walkways using commercial traffic paint to ensure clear traffic flow.
Safety & Access Considerations
Performing parkade waterproofing in vancouver requires meticulous planning under WorkSafeBC regulations. Our operations are governed by qualified SPRAT/IRATA technicians who conduct risk assessments, verify structural roof anchors, and set up secondary backup systems. We coordinate ground barricades to isolate work areas, keeping residents, shoppers, and pedestrians safe on the ground.
View Our Safety StandardsOther Services We Offer
Frequently Asked Questions
What is traffic membrane waterproofing?
It is a multi-layered polyurethane system designed to be flexible enough to waterproof concrete while being tough enough to withstand vehicle weight and tire friction.
How long does a parkade traffic coating last?
High-traffic drive lanes typically require touch-ups every 5-7 years, while parking stalls can last 10-15 years before needing a full re-application.
What is calcite (stalactite) dripping, and is it bad?
White mineral formations dripping from concrete ceilings. Water leaching through concrete carries calcium hydroxide, which damages car paint and signals structural concrete degradation.
How do you prepare parkade concrete for coatings?
We use industrial shot-blasters or diamond grinders to strip old paint and expose a clean concrete profile, ensuring strong coating adhesion.
Do you repair concrete cracks before applying the membrane?
Yes, we route all surface cracks and inject them with structural epoxy or flexible polyurethane resins to create a continuous waterproof seal.
Can you apply traffic coatings to parkade ramps?
Yes, we install specialized heavy-duty ramp coating systems with heavy aggregate profiling to provide extra traction for tires climbing steep, wet ramps.
Do you repaint parking lines after applying the membrane?
Yes, we perform full line striping, including parking stalls, accessibility symbols, directional arrows, and pedestrian walkways.
Is the parkade closed during the waterproofing project?
We split parkade projects into phases, closing only sections of the parkade at a time, allowing residents to park in other zones during installation.
How long does a parkade traffic coating take to cure?
Typically, the coated area is ready for light pedestrian traffic in 24 hours, and can accept vehicle traffic 48-72 hours after the final topcoat cures.
Do you offer a warranty on parkade traffic coatings?
Yes, we provide 5 to 10-year commercial warranties, backed by leading manufacturers, covering both materials and labor.
